JSON-RPC

The JSON-RPC specification is a remote procedure call protocol encoded in JSON based on OpenRPC. It allows calling functions on a remote server, and for the return of the results.

It is part of the Execution API specification which provides a set of methods to interact with the Ethereum blockchain. It is better known to be the way of how the users interact with the network using a client, even how the consensus layer (CL) and the execution layer (EL) interact through the Engine API.

This section provides a description of the JSON-RPC methods.

API Specification

The JSON-RPC methods are grouped by namespaces specified as a method prefix. Even though they all have different purposes, all of them share a common structure and must behave the same across all implementations:

{
  "id": 1,
  "jsonrpc": "2.0",
  "method": "<prefix_methodName>",
  "params": [...]
}

Where:

• id: A unique identifier for the request.
• jsonrpc: The version of the JSON-RPC protocol.
• method: The method to be called.
• params: The parameters for the method. It can be an empty array if the method does not require any parameters. Other ones may have default values if not provided.

Namespaces

Every method is composed of a namespace prefix and the method name, separated by an underscore.

Ethereum clients must implement the basic minimum set of RPC methods required by spec to interact with the network. On top of that, there are also client specific methods for controlling the node or implementing extra unique features. Always refer to client documentation listing available methods and namespace, for example notice different namespaces in Geth and Reth docs.

Here are examples of most common namespaces:

Sensitive means they could be used to set up the node, such as admin, or access account data stored in the node, just like eth.

Now, let's take a look at some methods to understand how they are built and what they do:

Eth

Eth is probably the most used namespace providing basic access to Ethereum network, e.g. it's necessary for wallets to read balance and create transactions.

Just a brief list of the methods is provided here, but the full list can be found in the Ethereum JSON-RPC specification.

Debug

The debug namespace provides methods to inspect the Ethereum state. It's direct access to raw data which might be necessary for certain use cases like block explorers or research purposes. Some of these methods might require a lot of computation to be done on the node and requests for historical states on non-archival node are mostly not feasible. Therefore, providers of public RPCs often restrict this namespace or allow only safe methods.

Here are basic examples of debug methods:

Engine

Engine API is different from the aforementioned general Ethereum JSON‑RPC methods. Execution clients serve the Engine API on a separate, authenticated endpoint rather than on the normal HTTP JSON‑RPC port because it is not a user-facing API. Its sole purpose is to facilitate inter-client communication exchanging information about consensus, fork choice, and block validation between the consensus and execution clients.

Inter-client communication operates over a JSON‑RPC interface over HTTP and is secured using a JSON Web Token (JWT). The JWT authenticates the sender as a valid consensus layer client, although it does not provide traffic encryption. Furthermore, the Engine JSON‑RPC endpoint is only accessible by the consensus layer, ensuring that malicious external parties cannot interact with it.

The following table lists core Engine API methods and provides a brief description of their purpose and the parameters they accept:

Those methods marked with an asterisk (*) have more than one version to support network upgrades and evolving protocol features. The Ethereum JSON-RPC specification provides detailed documentation on these methods.

Encoding

There is a convention for encoding the parameters of the JSON-RPC methods, which is the hex encoding.

• Quantities are represented as hexadecimal values using a "0x" prefix.
  • For example, the number 65 is represented as "0x41".
  • The number 0 is represented as "0x0".
  • Some invalid usages are "0x" and "ff". Since the first case does not have a following digit and the second one is not prefixed with "0x".
• Unformatted data is, such as hashes, account addresses or byte arrays are hex encoded using a "0x" prefix as well.
  • For example: 0x400 (1014 in decimal)
  • An invalid case is 0x400 because there are no leading zeroes allowed

Transport agnostic

Worth to mention here the JSON-RPC is transport agnostic, meaning it can be used over any transport protocol, such as HTTP, WebSockets (WSS), or even Inter-Process Communication (IPC).

Their differences can be summarized as it follows:

• HTTP transport provides an unidirectional response-request model, which gets the connection closed after the response is sent.
• WSS is a bidirectional protocol, which means the connection is kept open until either the node or the user explicitly closes it. It allows subscriptions-based model communication such as event-driven interactions.
• IPC transport protocol is used for communication between processes running on the same machine. It is faster than HTTP and WSS, but it is not suitable for remote communication, e.g. it can be used via local JS console.

Tooling

There are several ways of how to use the JSON-RPC methods. One of them is using the curl command. For example, to get the latest block number, you can use the following command:

curl <node-endpoint> \
-X POST \
-H "Content-Type: application/json" \
-d '{"jsonrpc":"2.0","method":"eth_blockNumber","params":[],"id":1}'

Please note how the params field is empty, as the method passes "latest" as its default value.

Another way is to use the axios library in Javascript/TypeScript. For example, to get the address balance, you can use the following code:

import axios from 'axios';

const node = '<node-endpoint>';
const address = '<address>';

const response = await axios.post(node, {
  jsonrpc: '2.0',
  method: 'eth_getBalance',
  params: [address, 'latest'],
  id: 1,
  headers: {
    'Content-Type': 'application/json',
  },
});

As you may notice, the JSON-RPC methods are wrapped in a POST request, and the parameters are passed in the body of the request. This is a different way to exchange data between the client and the server using the OSI's application layer: the HTTP protocol.

Either way, the most common use to interact with the Ethereum network is using web3 libraries, such as web3py for python or web3.js/ethers.js for JS/TS:

web3py

from web3 import Web3

# Set up HTTPProvider
w3 = Web3(Web3.HTTPProvider('http://localhost:8545'))

# API
w3.eth.get_balance('0xaddress')

ethers.js

import { ethers } from "ethers";

const provider = new ethers.providers.JsonRpcProvider('http://localhost:8545');

await provider.getBlockNumber();

Usually, all the web3 libraries wrap the JSON-RPC methods providing a more friendly way to interact with the execution layer. Please, look forward in your preferred programming language as the syntax may vary.
